Exhaust Gas Analyzer Main Function:

Plate imported functional group can store 500 measurements, real-time clock

Fission structure, measurement and control unit, convenient and simple

Opacity and absorption coefficient, N&K, simple operation

LCD large screen display, English menu clew operation

Free acceleration experiments and adopts the transient measurement function, and automatic processing of test data and display measurements

Preheating 15 minutes, and auto-zeroing

Test unit adopts shunt technique, test the diesel smoke level.Using”air curtain”technique to protect optical system against pollution

Built-in printer, real-time measurements of query and print

RS232 interface, convenient networking.

Gas temperature and engine speed optional   configuration

Exhaust Gas Analyzer Main Technical Parameter:

Measurement range: Dark lighting N:0-99.9%

Optical absorption coefficient K: 0-16.00m-1

Resolution: Opacity N: 0.1%

Coefficient of light absorption K:0.01m-1

Indication Error:   Opacity N: ±2.0%(absolute error)

Power: AC 220V; 50HZ

Weight:    Test unit: 13.5Kg

         Control unit: 6kg (include printer)

Volume:  Control unit: 610*500*330 mm

       Test unit: 500*300*33 0mm

Preheating time: 10 minutes

If any more questions about the OC-502 diesel engine exhaust gas analyzer , welcome to contact with us.
