OC-850 multi portable gas detector is a highly customizable handheld industrial gas monitoring device, supporting 1~5 kinds of gas customization, configured with four independent high-precision electrochemical sensors for O3 Ozone, NO2 Nitrogen Dioxide, SO2 Sulfur Dioxide, CO Carbon Monoxide.
Gas detector, gas alarm, portable gas detector, portable gas alarm
Product Overview
OC-850 multi portable gas detector is a highly customizable handheld industrial gas monitoring device, supporting 1~5 kinds of gas customization, configured with four independent high-precision electrochemical sensors for O3 Ozone, NO2 Nitrogen Dioxide, SO2 Sulfur Dioxide, CO Carbon Monoxide.
It supports dual sampling modes: standard diffusion sampling and optional 1L/min pump suction sampling, perfectly suitable for pipeline sampling, confined space inspection, factory flue gas testing and environmental field monitoring. Adopts imported industrial electrochemical sensors, effectively reduce cross interference between acidic and oxidizing toxic gases, deliver stable and accurate test data.
Equipped with high-definition LCD display, real-time show gas concentration, gas name and alarm status. Built-in stainless steel filter screen blocks acid mist, dust and oil fume to protect internal sensors. It supports 9999 groups of alarm data storage for safety record checking.
With Ex ib IIB T3 explosion-proof grade and IP65 dustproof waterproof rating, triple sound-light-vibration alarm. Large capacity battery provides up to 100 hours long standby time when pump is closed. Widely applied to environmental law enforcement, thermal power plants, smelting factories, coating workshops, chemical enterprises and atmospheric pollution sampling inspection.
Core Features
Custom 4-gas solution O3 Ozone, NO2 Nitrogen Dioxide, SO2 Sulfur Dioxide, CO Carbon Monoxide, etc. Match atmospheric monitoring and industrial acid flue gas detection demands
Four separated imported electrochemical sensors, low cross interference for mixed oxidizing toxic gases
Dual sampling optional: diffusion sampling & 1L/min pump suction sampling for deep pipeline & confined space detection
Compatible with Electrochemistry, NDIR, PID sensors, flexible upgrade for different detection needs
Stainless steel pre-filter screen block acid mist and particles, extend sensor service life
LCD real-time display data, support PPM, %VOL, mg/m³ multiple unit switch
Store max 9999 groups alarm records, convenient for factory safety management filing
Sound + light + vibration triple alarm, obvious warning in noisy industrial workshops
Ex ib IIB T3 explosion proof + IP65 waterproof dustproof, adapt harsh outdoor working conditions
Ultra-long 100 hours standby without pump, lightweight 300g body for daily patrol
Technical specification:
| Gas Detected | O₃, NO₂, SO₂, CO. | ||
| Detection principle | Electrochemical Sensors. | ||
| Sampling Method | Diffusion type or Pump suction(1L/min) | ||
| Measure Range | CO: 0~1000ppm, NO2: 0~100ppm, SO2: 0~20ppm, O3: 0~5ppm. Support customized | ||
| Resolution | CO: 1ppm, NO2: 0.1ppm, SO2: 0.01ppm, O3: 0.01ppm. | ||
| Precision | ≤± 3% F.S. | ||
| Data store | 9999 groups alarm information | ||
| Response Time | ≤10S | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%（F.S/Y） | Display | LCD screen |
| Operating language | English or Chinese | Gas unit | PPM, %VOL, %LEL |
| Temperature | -40～70℃ | Humidity | 0-95%RH |
| Explosion-Proof | Ex ib IIB T3 | Protection level | IP65 |
| Alarm mode | Sound, light and vibration | Operating time | 100hours（off pump） |
| Dimensions | 205*75*32mm | Weight | 300g |
