OC‑905 pump‑suction portable biogas detector with imported sensors for CH4,CO2,H2S,O2,100000‑group data storage & USB export, two‑stage sound‑light alarm, Ex ib IIC T4 Gb explosion‑proof for biogas plant, landfill and sewage‑treatment safety inspection.
Description:
OC‑905 portable pump‑suction biogas detector adopts famous‑brand original imported sensors and ultra‑low‑power 32‑bit microprocessor. Equipped with built‑in sampling pump with stable 300 ml/min flow rate for active suction sampling, it is customized for biogas components detection (CH4 methane, CO2 carbon dioxide, H2S hydrogen sulfide, O2 oxygen). With four‑layer circuit wiring, intelligent algorithm, multi‑point calibration and temperature compensation, it achieves stable performance and high measuring accuracy. The 2.5‑inch dot‑matrix LCD screen directly displays real‑time biogas‑component concentration data. It supports up to 100 000 groups measurement‑data storage, and historical records can be exported to computer via USB cable. Two‑stage adjustable audible‑visual alarm will activate when any gas concentration reaches preset threshold. Featuring all‑English operation menu, aluminum‑alloy metal housing, Ex ib IIC T4 Gb explosion‑proof grade and IP54 protection grade, this handheld unit is widely applied in biogas digester plant, landfill site, sewage‑treatment plant, farm anaerobic fermentation station and other biogas‑related working sites.
Features:
Used original imported sensors and ultra-low power 32 bit microprocessor
The circuit adopts 4-layer wiring, which is stronger for weak signal processing and anti-interference ability
Intelligent algorithm + multi-point calibration + temperature compensation, more accurate measurement results
2.5 inch dot matrix display interface,reading intuitively
All English operation menu and easy operation.
| Gas type | biogas |
| Working principle | Electrochemical sensor |
| Measuring range | 0~100%LEL or customized |
| Resolution | 0.1ppm 0.1%LEL or customized |
| Concentration unit | %LEL, %Vol, ppb, ppm，mg/m3 |
| Precision | ±≤3%F.S |
| Repeatability | ≤±2% |
| Zero drift | ≤±1%(F.S/year) |
| Sampling mode | Pump-suction sampling (Flow rate of 300ml/minute) |
| Data storage | Can record 100000 group of measuring data |
| Response time | T90≤30s (different gas sensors have different response times) |
| Recovery time | ≤20s |
| Pre-heating time | ≤60s |
| Display | LCD dot matrix display of the Gas type, gas concentration unit, gas concentration data, time, battery status, data storage status; |
| Working temperature | -20℃～50℃(Special requirements need to be customized) |
| Working humidity | 10%-95%RH(non-condensing) |
| Working pressure | 86Kpa~106Kpa |
| Explosion-Proof grade | Ex ib IIC T4 Gb |
| Protection grade | IP54 |
| Alarm mode | Audible, visual. Two-color LED alarm light, sound≥75dB@25cm |
| Shell material | Aluminum alloy metal housing, ABS+PC |
| Power supply | 3.7VDC, 2600mAh,Rechargeable lithium battery DC5V USB charger |
| Charge time | ≤6 hours |
| Working time | ≥12 hours (Normal temperature electrochemical sensor) |
| Power consumption | 0.5W |
| Dimensions | 200.5*64.8*35.5mm （L*W*H） |
| Weight | 0.46KG |
| Accessory | Box, instruction, USB charger , data line |
| Quality standard | GB15322.1-2003,GB3836.1-2010,GB3836.2-2010,GB3836.4-2010,GB12358-2006 |
Application field:
Biogas digester & anaerobic fermentation project inspection
Landfill gas monitoring and biogas‑utilization station test
Sewage‑treatment plant biogas‑related safety patrol
Livestock farm biogas‑generation site detection
Biogas upgrading and biomethane quality‑check work
